16 | Dome EX Display
Dome E2 Specification
In locations where 240V outlets are used, connect the Dome E2 display to only a center-
tapped, 240V, single-phase supply (only for Canada and the United States).
Category Characteristic Item Specification
Screen Screen size diagonal 498 mm (19.6 in.)
Resolution 1200 x 1600 pixels (portrait)
1600 x 1200 pixels (landscape)
Pixel pitch 0.249 mm x 0.249 mm
Pixel arrangement Subpixel vertical stripe
Active area (mm) 398.4 (H) x 298.8 (V)
Grayscale supported 3061 shades of gray
Refresh rate 60 Hz
Contrast ratio 600:1 (typical)
Brightness 900 cd/m
2
(when new)
Pixel rise/fall time 40 ms (typical)
Viewing angle 170° (± 85°) horizontal/vertical
Interface Digital Video In DVI Rev. 1.0 single digital channel connector
Display control - brightness/
contrast
DDC2B+
Display identification EDID read using DDC2B+
USB hub Universal Serial Bus (USB) Rev. 1.1:
1 uplink B port; 2 downlink A ports
Display status Dual-stack tricolor LEDs on back panel
Input formats Landscape orientation 1600 x 1200 (8-bit and 24-bit per pixel)
Portrait orientation 1200 x 1600 (8-bit and 24-bit per pixel)
VGA to XGA/SXGA 640 x 480 to 1024 x 768 in both landscape and
portrait rotations, 1280 x 1024 displayed in
landscape rotation
Screen type AMLCD (active matrix liquid crystal display)
Physical Display size (without stand) 440 mm x 343 mm x 95 mm
(17.3 in. x 13.5 in. x 3.75 in.)
Display weight (without stand) 5.5 kg (12 lb)
Mounting options Desktop stand (standard);
100-mm VESA mounting (optional)
Power Adapter Ault MW116KA1249F53 (CAUTION: Use only the
power adapter supplied with the display unit.)
