24 | Dome EX Display
Dome E5 Specification
Model 933-0544-00
In locations where 240V outlets are used, connect the Dome E5 display to only a center-
tapped, 240V, single-phase supply (only for Canada and the United States).
Category Characteristic Item Specification
Screen Screen size diagonal 510 mm (20.1 in.)
Resolution 2048 x 2560 pixels (portrait)
2560 x 2048 pixels (landscape)
Pixel pitch 0.156 mm, 163 ppi
Pixel arrangement Subpixel vertical stripe
Active area (mm) 399.4 (H) x 319.58 (V)
Grayscale supported 3061 shades of gray
Refresh rate 60 Hz
Contrast ratio 600:1 (typical)
Brightness 850 cd/m
2
(typical)
Pixel rise/fall time 30 ms (typical)
Viewing angle 170° (± 85°) horizontal/vertical
Interface Digital Video In DVI Rev. 1.0 single digital channel connector
Display control - brightness/
contrast
DDC2B+
Display identification EDID read using DDC2B+
USB hub Universal Serial Bus (USB) Rev. 1.1:
1 uplink B port; 2 downlink A ports
Display status Dual-stack tricolor LEDs on back panel
Input formats Landscape orientation 2560 x 2048 (8-bit per pixel)
Portrait orientation 2048 x 2560 (8-bit per pixel)
VGA to XGA/SXGA 640 x 480 to 1024 x 768, 1280 x 1024 displayed in
both landscape and portrait rotations
Screen type AMLCD (active-matrix liquid crystal display)
Physical Display size (without stand) 362 mm x 442 mm x 103 mm
(14.3 in. x 17.4 in. x 4.1 in.)
Display weight (without stand) 5.9 kg (13 lb)
Mounting options Desktop stand (standard);
100-mm VESA mounting (optional)
Power Adapter Ault MW122RA1223F52 (CAUTION: Use only the
power adapter supplied with the display unit.)
