RS232 Codes
EP4650 and EP5550 RS232 User Guide 5
Main Item
Control
Item
CMD Type
Value
(DEC)
Reply
(DEC)
Content
CMD
(HEX)
Notes
Other
Control
Wake Up
From Sleep
WFS W/R
0 0 Set VGA_ONLY
57 46 53
1 1 Set
VGA_DIGITAL_RS232
2 2 Set Never_Sleep
Audio
VOL
W/R
0~100 Current value volume 56 4F 4C
MUT
00 00 Mute Off 4D 55 54
01 01 Mute On
Scheme
Selection
SCM W/R
00 00 User
53 43 4D
01 01 Sport
02 02 Game
03 03 Cinema
04 04 Vivid
Multi-
Display
VWS
W/R
00 00 Video Wall Switch Off
56 57 53
01 01 Video Wall Switch On
VWF
00 00 Video Wall Frameless
Off
56 57 46
01 01 Video Wall Frameless
On
MAT X: 1-5
Y: 1-5
Current value
Matrix X, Y value
High quarter is X: 7-4
bit
Low quarter is Y: 3-0 bit
4D 41 54
DIV X: 1-5
Y: 1-5
Current value
Divisions X, Y value
High quarter is X: 7-4
bit
Low quarter is Y: 3-0 bit
44 49 56 Note 1
DID
00 00 DVI Indemnity Off
44 49 44
01 01 DVI Indemnity On
POD 0-30 Current value Integral part of Power
On Delay (0-30 sec.)
50 4F 44
