RS232 Codes
EP4650 and EP5550 RS232 User Guide 7
※: The RS232 transition will be blocked for around six seconds after a power on/off
command has been performed.
Note 1: In broadcast setting mode, this command is used to auto arrange the Division X/Y.
(The Value Byte needs to be 0x11.)
Main Item
Control
Item
CMD Type
Value
(DEC)
Reply
(DEC)
Content
CMD
(HEX)
Notes
RTC
Tuesday
ENH
W/R
0~23 0~23 Tuesday On Hour 45 4E 48
ENM 0~59 0~59 Tuesday On Minute 45 4E 4D
EFH 0~23 0~23 Tuesday Off Hour 45 46 48
EFM 0~59 0~59 Tuesday Off Minute 45 46 4D
Wednesday
DNH
W/R
0~23 0~23 Wednesday On Hour 44 4E 48
DNM 0~59 0~59 Wednesday On Minute 44 4E 4D
DFH 0~23 0~23 Wednesday Off Hour 44 46 48
DFM 0~59 0~59 Wednesday Off Minute 44 46 4D
Thursday
UNH
W/R
0~23 0~23 Thursday On Hour 55 4E 48
UNM 0~59 0~59 Thursday On Minute 55 4E 4D
UFH 0~23 0~23 Thursday Off Hour 55 46 48
UFM 0~59 0~59 Thursday Off Minute 55 46 4D
Friday
INH
W/R
0~23 0~23 Friday On Hour 49 4E 48
INM 0~59 0~59 Friday On Minute 49 4E 4D
IFH 0~23 0~23 Friday Off Hour 49 46 48
IFM 0~59 0~59 Friday Off Minute 49 46 4D
Saturday
TNH
W/R
0~23 0~23 Saturday On Hour 54 4E 48
TNM 0~59 0~59 Saturday On Minute 54 4E 4D
TFH 0~23 0~23 Saturday Off Hour 54 46 48
TFM 0~59 0~59 Saturday Off Minute 54 46 4D
