Planar PL1900 User Manual

8
Installation Instructions
Power Source:
1. Make sure that the power cord is the correct type required in your
area.
2. This LCD monitor has an External universal power supply that
allows operation in either 100/120V AC or 220/240V AC voltage
area (No user adjustment is required.)
3. Connect the AC-power cord into your LCD monitor’s External
Adapter input socket, and then plug the other end of External
adapter to LCD monitor’s DC-power-input. The AC-power cord may
be connected to either a wall power outlet or the power outlet
socket on your PC, depending on the type of power cord supplied
with your LCD monitor.

Planar PL1900 Specifications

General

Screen Size	19 inches
Resolution	1280 x 1024
Aspect Ratio	5:4
Brightness	250 cd/m²
Contrast Ratio	1000:1
Response Time	5 ms
Connectivity	VGA, DVI
Viewing Angle (Horizontal)	170°
Viewing Angle (Vertical)	160°
Panel Type	TN
