Installation Instructions
CABLE CONNECTIONS
Connecting the Signal Cable: the LCD monitor comes with a built-in
signal cable. Plug the signal cable′s 15-pin connector into the
computer's VGA port and tighten the two screws on the cable
connector.
Connecting the Power Cord: Plug the AC-power cord into the External
Adapter. Then plug the DC-jack power cable into DC-IN Inlet.
Caution: If the AC outlet is not grounded (with three holes), install the
proper grounding adapter (not supplied).
Figure 1 Connecting Cables
1.
DC-Jack Power Cable 2. Signal Cable
3.
AC Power Cord
