Planar PT3290PW - RS232 Monitor Control

9
(Figure 8.1)
Controlling the PT3290PW monitor via RS232 (Optional)
The PT3290PW monitor can be controlled by connecting to a PC with a RJ45 terminal
diagramed below:
Note:
Two COM Ports are reserved for this option.
Please refer to the RS232 section starting on page 13 for more information.
RJ45 In RJ45 Out
RJ45 In
