VESA Mount for Your Monitor
This monitor conforms to the VESA Flat Panel Mounting Physical Mounting Interface
standard which de fines a physical mounting interface for flat panel monitors, and
corresponding with the standards of flat panel monitor mounting devices, such as wall and
table arms. The VESA mounting interface is located on the back of your monitor.
To mount the monitor on a UL certi fied swing arm or other mounting fixture, follow the
instructions included with the mounting fixture to be used.
!
Warning!
Please select the proper screws!
The distance between the back cover surface and the bottom of the screw hole
is 10 mm. Please use four M4 screws diameter with proper length to mount your
monitor.
Please note: the optional mount must be able to support at least 44 lbs (20Kg).
6
200.00mm 200.00mm
200.00mm
200.00mm
8-M4
