The monitor shall synchronize with any vertical frequency from 56.25 Hz to 85.08 Hz, and with any
horizontal frequency from 31 .469KHz to 91.146 KHz. If the input frequency is out of the above-specified
range, the monitor shall display a warning screen indicating that the input frequency is out of range.
Under no circumstances shall any combination of input signals cause any damage to the monitor.
Compatible modes see Figure 1
Figure 1 Compatible modes
Resolution V Freq. (Hz) H Freq. (KHz) Standard
640 x 350 85.08 37.861 VESA
640 x 400 85.08 37.861 VESA
640 x 480 59.94 31.469 VESA
640 x 480 72.809 37.861 VESA
640 x 480 85.008 43.269 VESA
720 x 400 70.087 31.469 IBM
720 x 400 85.039 37.927 VESA
800 x 600 56.25 35.156 VESA
800 x 600 60.317 37.879 VESA
800 x 600 72.188 48.077 VESA
800 x 600 85.061 53.674 VESA
1024 x 768 60 48.363 VESA
1024 x 768 70.069 56.476 VESA
1024 x 768 75.029 60.023 VESA
1024 x 768 84.997 68.677 VESA
1152 x 864 70.012 63.851 VESA
1280 x 720 59.856 44.772 VESA
1280 x 768 59.87 47.776 CVT
1280 x 960 85.002 85.938 VESA
1360 x 768 59.96 47.368 VESA
1360 x 768 74.892 60.288 VESA
1366 x 768 59.79 47.712 VESA
1280 x 1024 60.02 63.981 VESA
1280 x 1024 75.025 79.976 VESA
1280 x 1024 85.024 91.146 VESA
1680 x 1050 59.954 65.29 CVT
1920 x 1080 59.934 66.587 VESA
