Planet GS-4210-24T2S Quick Installation Guide

17
GS-4210-16T2S
PWR
2
1
4
3
6
5
8
7
12
11
10
9
14
13
16
15
Reset
18
17
16-Port 10/100/1000T + 2-Port 100/1000X SFP Managed Switch
ACTLNK1000
ACTLNK10/100
ACTLNK1000
ACTLNK100
Reset
Figure 5-4: GS-4210-16T2S Reset Button
1 3 5 7 9 11 13 15
RESET
2 4 6 8 10 12 14 16
17
18
PWR
GS-4210-16P2S
16-Port 10/100/1000T 802.3at PoE
+
2-Port 100/1000X SFP Managed Switch
ACTLNK1000
ACTLNK10/100
ACTLNK1000
ACTLNK100
PoE-in-Use
Reset
Figure 5-5: GS-4210-16P2S Reset Button
Reset
GS-4210-16P4C
2
1
6
5
4
3
8
7
10
9
14
13
12
11
16
15
18
17
18
17
20
19
20
19
PoE
SYS
PWR
100
1000
LNK/ACT
LNK/ACT
10/100 LNK/ACT
1000 LNK/ACT
PoE-in-Use
Console
115200,N,8,1
Reset
Figure 5-6: GS-4210-16P4C Reset Button
GS-4210-24T2S
PWR
2
1
4
3
6
5
8
7
12
11
10
9
14
13
18
17
16
15
20
19
22
21
24
23
Reset
26
25
24-Port 10/100/1000T + 2-Port 100/1000X SFP Managed Switch
ACTLNK1000
ACTLNK10/100
ACTLNK1000
ACTLNK100
Reset
Figure 5-7: GS-4210-24T2S Reset Button

Planet GS-4210-24T2S Specifications

General

Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
10G support	No
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Security algorithms	HTTPS, SNMP
Throughput	38.6 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Supported network protocols	IPv4/IPv6 IP-based ACL / MAC-based ACL
Stackable	-
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Blue
LED indicators	Link, Power, System
Housing material	Metal
Input current	0.8 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	14 W
Heat dissipation	47 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	207 mm
Width	445 mm
Height	45 mm
Weight	2100 g
