Planet GS-4210-24T2S Quick Installation Guide

18
1 3 5 7 9 11 13 15 17 19 21 23
2
PWR
RESET
4 6 8 10 12 14 16 18 20 22 24
25
26
GS-4210-24P2S
24-Port 10/100/1000T 802.3at PoE
+
2-Port 100/1000X SFP Managed Switch
ACTLNK1000
ACTLNK10/100
ACTLNK1000
ACTLNK100
PoE-in-Use
Reset
Figure 5-8: GS-4210-24P2S Reset Button
3
4
1
2
Reset
GS-4210-24P4C
SYS
PWR
100
1000
LNK/ACT
LNK/ACT
2
1
6
5
4
3
8
7
10
9
14
13
12
11
16
15
18
17
22
21
20
19
24
23
26
25
26
25
28
27
28
27
PoE
10/100 LNK/ACT
1000 LNK/ACT
PoE-in-Use
Reset
Figure 5-9: GS-4210-24P4C/GS-4210-24PL4C Reset Button
PWR
2
1
4
3
6
5
8
7
12
11
10
9
14
13
18
17
16
15
20
19
22
21
24 25 26 27 28
23
Reset
9
10
3
4
5
6
7
8
1
2
ACTLNK1000
ACTLNK10/100
ACTLNK1000
ACTLNK100
Reset
Figure 5-10: GS-4210-24T4S/GS-4210-24T4SR Reset Button
49 51
50PWR
SYS
Reset
49 50
115200, N, 8, 1
Console
52
51 52
1000
ACTLNK
ACTLNK
10/100
1000X
ACTLNK
ACTLNK
100X
35
36
38
40
42 44
46
37 39 41 43 45 47
48
Reset
Figure 5-11: GS-4210-48T4S Reset Button

Planet GS-4210-24T2S Specifications

General

Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
SFP module slots quantity	2
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
10G support	No
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Security algorithms	HTTPS, SNMP
Throughput	38.6 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Supported network protocols	IPv4/IPv6 IP-based ACL / MAC-based ACL
Stackable	-
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Blue
LED indicators	Link, Power, System
Housing material	Metal
Input current	0.8 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	14 W
Heat dissipation	47 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	207 mm
Width	445 mm
Height	45 mm
Weight	2100 g
