3. Terminal Setup
Tocongure the system,connect aserialcable toaCOM port ona PC ornotebook
computerandtoDB9typeofserialportoftheL2+ManagedPoE+Switch.
Managed Switch
PC / Workstation
with
Terminal Emulation Software
Serial Port
RS232 to RJ45 Cable
Console Port
RJ45
Figure 3-1: L2+ Managed PoE+ Switch Console Connectivity
A terminalprogram, such as Tera Term orPuTTY, is required tomake thesoftware
connectiontotheL2+ManagedPoE+Switch.
1. Run terminal program on the OS.
2.When the following screen appears, make sure that the COM port should be
conguredas:
z Baud:115200
z Databits:8
z Parity:None
z Stopbits:1
z Flowcontrol:None
Figure 3-2: COM Port Conguration
