3.1 Desktop Installation
To install the Switch on desktop, simply follow the next steps:
Step 1: Place the Switch on desktop near an AC power source.
Step 2: Keep enough ventilation space between the Switch and the surrounding
objects.
When choosing a location, please keep in mind the environmental
restrictions discussed in Chapter 1, Section 4, in Specification.
Step 3: Connect your Switch to 802.3af complied Power Devices (PD) and other
network devices.
A. Connect one end of a standard network cable to the 10/100/1000
RJ-45 ports on the front of the Switch.
B. Connect the other end of the cable to the network devices such as
printer servers, workstations or routers…etc.
Connection to the Switch requires UTP Category 5 network cabling
with RJ-45 tips. For more information, please see the Cabling Spec-
ification in Appendix A.
Step 4: Supply power to the Switch.
A. Connect one end of the power cable to the Switch.
B. Connect the power plug of the power cable to a standard wall outlet.
When the Switch receives power, the Power LED should remain solid Green.
