2. Hardware Description
This product provides three different running speeds – 10Mbps, 100Mbps and
1000Mbps in the same switch and automatically distinguishes the speed of
incoming connection.
This section describes the hardware features of GSD-804P. For easier management
and control of the Switch, familiarize yourself with its display indicators, and ports.
Front panel illustrations in this chapter display the unit LED indicators. Before
connecting any network device to the GSD-804P, please read this chapter carefully.
In the following section, the term “Switch” means the Switch device, ie. GSD-
804P; term of “switch” can be any third switches.
2.1 Front Panel
The Front Panel of the GSD-804P PoE Ethernet Switch consists of 8x Auto-Sensing
10/100/1000Mbps Ethernet RJ-45 Ports. The LED Indicators are also located on the
front panel of the GSD-804P.
Figure 2-1: GSD-804P Switch Front Panel
