HDP-5240PT
45
Advanced
Field Name Explanation
Link Layer Discovery Protocol (LLDP) Settings
Enable LLDP Enable or Disable Link Layer Discovery Protocol (LLDP).
Enable Learning Function
Enables the telephone to synchronize its VLAN data with the Network Switch.
The telephone would automatically synchronize DSCP, 802.1p, and VLAN ID
values even if these values differ from those provided by the LLDP server.
Packet Interval (1~3600) The time interval of sending LLDP Packets
VLAN Settings
Enable VLAN Enable or Disable WAN port VLAN.
VLAN ID Specify the value of the VLAN ID. Range is 0-4095.
802.1p Signal Priority Specify the value of the signal 802.1p priority. Range is 0-7.
802.1p Media Priority Specify the value of the voice 802.1p priority. Range is 0-7.
Quality of Service (QoS) Settings
Enable DSCP QoS Enable or Disable Differentiated Services Code Point (DSCP).
Media QoS Priority Specify the value of the Media DSCP in decimal.
Signal QoS Priority Specify the value of the Signal DSCP in decimal.
