7
Power over Ethernet
PoE Standard
IEEE 802.3at High Power over Ethernet /
mid-span PSE
PoE Power
Output
DC 24~48V
Input
30 watts
DC 12V Input 25 watts
PoE Power Supply Type Mid-span
Power Pin Assignment 4/5(+), 7/8(-)
Standards Conformances
Standards Compliance
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
IEEE 802.3af Power over Ethernet
IEEE 802.3at Power over Ethernet Plus
FCC FCC Part 15B Class A
CE
EMI
EN 55022
EN 61000-3-2
EN 61000-3-3
EMS
EN 61000-4-2 (ESD)
EN 61000-4-3 (RS)
EN 61000-4-4 (EFT)
EN 61000-4-5 (Surge)
EN 61000-4-6 (CS)
EN 61000-4-8 (PFMF)
Stability Testing
IEC60068-2-32 (Free fall)
IEC60068-2-27 (Shock)
IEC60068-2-6 (Vibration)
Environment
Operating Temperature -40 ~ 75 degrees C
Storage Temperature -40 ~ 85 degrees C
Humidity 5 ~ 95% (non-condensing)
Note
The PoE power output ability will depend on the
distance.
