4.2 Product Outlook
Figure 4-2 IPOE-162 outlook
LED Indicators
LED Color Function
P1 Green Indicates Power 1 has power.
P2 Green Indicates Power 2 has power.
FAULT Red
Indicates either Power 1 or Power 2 has no
power.
PoE in-Use Orange
Indicates the port is providing 56V DC in-line
power.
