Planet IPOE-470 User Manual

5
LED Indicator
System:
Power 1 (Green)
Power 2 (Green)
Alarm (Red)
PoE Usage:
80W/160W/240W (Amber)
802.3bt PoE++ Port:
PoE-in-use x 1 (Amber)
ESD Protection 6KV
Surge Protection 6KV
Network Cable
Twisted-pair cable up to 100 meters (328ft)
10BASE-T: 4-pair UTP Cat. 3, 4, 5, 5e, 6
100BASE-TX: 4-pair UTP Cat. 5, 5e, 6
1000BASE-T: 4-pair UTP Cat. 5e, 6
Power over Ethernet
PoE Standard
IEEE 802.3bt PoE++, 4-pair type 4 PSE
Backward compatible with IEEE 802.3at PoE+ PSE
PoE Power
Supply Type
802.3bt PoE++ End-span + Mid-span
802.3at PoE+ End-span/Mid-span
Power Pin
Assignment
Pair 1 End-span: 1/2(-), 3/6(+)
Pair 2 Mid-span: 4/5(+), 7/8(-)
802.3bt: 1/2(-), 3/6(+), 4/5(+), 7/8(-)
PoE Power
Output
Max. 95 watts to 802.3bt PoE++ PD
Max. 60 watts to force-powered PD
Max. 36 watts to 802.3at PoE+ PD
PoE Power
Budget (max.)
240W@52V DC input
120W@48V DC input
240W@48~54V DC input
120W@24~47V DC input
60W@12~23V DC input
Number of
devices that can
be powered
4
