13
 System
LED Color Function
PWR Green
Lights to indicate above 48VDC input
Blinks for 2 secondstoindicate>44VDC,≤
48VDC
Blinks for 4 secondstoindicate>40VDC,≤
44VDC
Blinks for 4 seconds and TP ports ash
orange for 1 second to indicate the input
power is lower than 40VDC
30W IN Green
Lights to indicate IPOE-E174 is working in
2-pair mode and offers up to 30-watt power.
60W+ IN Green
Lights to indicate IPOE-E174 is working in
4-pair mode and offers more than 60-watt
power.
 PoE Power Usage
LED Color Function
20W Green
Blinks to indicate the system is providing 10W
~ 20W PoE power usage.
Lights to indicate the system is providing 20W
~ 30W PoE power usage.
40W Green
Blinks to indicate the system is providing 30W
~ 40W PoE power usage.
Lights to indicate the system is providing 40W
~ 50W PoE power usage.
60W Green
Blinks to indicate the system is providing 50W
~ 60W PoE power usage.
Lights to indicate the system is providing
60W+ PoE power usage.
