2.3 802.3at/bt PoE+ Output Port
Figure 2-3 shows the two PoE+ ouput ports side of the IPOE-E302.
Figure 2-3: IPOE-E302 PoE++ Output ports side
2.4 LED Indicators
LED Color Function
LNK/ACT Green
Lights to indicate the port is linked up at
10/100/1000Mbps.
Blinks to indicate that the IPOE-E302 is actively sending
or receiving data over that port.
