Planet ISW-500T User Manual

4
2.ProductSpecications
Product ISW-500T ISW-800T
HardwareSpecications
Hardware Version 2
Copper Ports
5 x 10/100BASE-TX RJ45
TP auto-MDI/MDI-X,
auto negotiation
8 x 10/100BASE-TX RJ45
TP auto-MDI/MDI-X,
auto negotiation
Connector
Removable 6-pin terminal block
Pin 1/2 for Power 1; Pin 3/4 for fault alarm; Pin 5/6
for Power 2
Alarm
Provides one relay output for power failure.
Alarm relay current carry ability: 1A@DC 24V
LED
3 x LED for system and power:
 Green: DC Power 1
 Green: DC Power 2
 Red: Power Alarm
1 x LED for each copper port:
 Green: 10/100Mbps LNK/ACT
ESD Protection 6KV
EFT Protection 6KV
Power Requirements
12~48V DC, redundant power with reverse polarity
protection function, 24V AC power support
Power Consumption /
Dissipation
Max. 1.1 watts/3.77BTU
(Power on without any
connection)
Max. 2 watts/6.86BTU
(Ethernet full loading)
Max. 1.1 watts/3.77BTU
(Power on without any
connection)
Max. 2.5 watts/8.57BTU
(Ethernet full loading)
Installation DIN-rail kit and wall-mount ear
Enclosure IP30 metal case
Dimensions (W x D x H) 30 x 70 x 104 mm 41 x 70 x 115 mm
Weight 255g 300g
