4
LED indications:
Printing LED Status Description
ON The chassis is powered PWR
OFF
The chassis is not powered or power failure if the
AC outlet is with 100~240V AC voltage. Please
consult your local dealer if power failure.
ON The fan is functional O.K FAN A /
FAN B
OFF
The fan is not powered or it is malfunction. If the
fan LED remains off while power is on. Please
consult your local dealer to replace the FAN.
The rear panel of the MC-1500 is with two fans, one ON/OFF Switch and a
power inlet that accept 100~240V AC, 50/60Hz power input.
Fig. 2 Rear view of MC-1500
The front panel of the MC-700 is as below:
l 7 open slots for media converters
l 2 LED indicators for system and fans
Fig. 3 Front View of 10-inch Converter Chassis MC-700
