5. Starting Web Management
The following shows how to start up the Web Management of the Managed
Metro Switch. Note the Managed Metro Switch is congured through an
Ethernet connection. Please make sure the manager PC must be set to the
same IP subnet address.
For example, the default IP address of the Managed Metro Switch is
192.168.0.100,then the manager PCshouldbesetto192.168.0.x(wherex
is a number between 1 and254, except 100), andthe default subnetmask is
255.255.255.0.
PC / Workstation
with Web Browser
192.168.0.x
Managed Switch
RJ45/UTP Cable
IP Address:
192.168.0.100
Figure 5-1: IP Management Diagram
