Planet POE-151 User Manual

- 5 -
1.4 Specification
Model POE-151
Ethernet Connector 2 x RJ-45( 1 for data + DC in, 1 for Data out)
Ethernet Data rate 10/100Mbps( vary on Ethernet device attached)
Input voltage DC 48V, 0.4A
Number of device can be powered 1
Ethernet cable TIA/EIA-568, Category 5/5e cable
LED indicator 1 x power, 1 x POE ready / in-use
Dimension (W x D x H) 73 x 55 x 24 mm
EMI FCC Class B, CE mark
Standard Compliance IEEE 802.3 Ethernet,
IEEE 802.3u Fast Ethernet,
IEEE 802.3af Power over Ethernet.
1.5 Product Outlook
LED definition:
LED Color Function
Power Yellow Lights to indicate that the POE-151 has power.
PoE ready / in-use Green Lights to indicate the port is providing 48VDC in-line power.
