3. Terminal Setup
Tocongure the system,connectaserial cabletoaCOMport onaPCornotebook
computerandtoRJ-45typeofconsoleportoftheManagedSwitch.
Managed Switch
PC / Workstation
with
Terminal emulation software
Serial Port
Serial Port
115200,8,n,1
RS-232 to RJ-45 Cable
Figure 3-1: Managed Switch Console Connectivity
A terminal program is required to make the software connection to the Managed
Switch.
1. Run terminal program on the OS.
2.When the following screen appears, make sure that the COM port should be
conguredas:
zBaud :115200
zDatabits :8
zParity :None
zStopbits :1
zFlowcontrol :None
Figure 3-2: COM Port Conguration
