Plastimo S Series User Manual

2
ASSEMBLY INSTRUCTIONS FOR S-SERIESASSEMBLY INSTRUCTIONS FOR S-SERIES
406-S 608-S 810-S406-S 608-S 810-S
I N D E X
Technical specifications of 406-S, 608-S, 810-S 3
Description of specific parts for each model 6
Tools needed 8
FLAT ASSEMBLY (forestay dismantled)
Dismantling the forestay 9
Assembly of the jib reefing system 10
IN SITU ASSEMBLY (directly onto the boat)
Measuring the length of the forestay 13
Cutting the last spar 14
Assembling the top end stop 15
Assembling the spars 15
Assembling the base spar 17
Assembling the boltrope prefeeder 18
Assembling the drum unit 18
Adjusting the reefing line feeders 19
RECOMMENDATIONS
Recommendations 20
Maintenance 21
Troubleshooting 21
OPTIONS
Optional extras 22
Spare parts 23
