Page #23 background image
23
Référence Reference N° 406-S 406-S
25722 25723
A 25752 Base 1 1
B 25392 Alloy spar 3 3
C 25384 Coupling sleeve 4 4
D 26179 PVC liner 4 4
E 25675 Screw TCL M4 x 12 2 2
F 22827 Bearing 2 2
G 10001 Drum 1 1
10003 "
10008 "
H 26324 Reefing line adjuster 1 1
I 26325 Coupling plates 5 holes 1
21308 11 holes 1
21291 5 holes
21295 11 holes
22850 5 holes
J 18109 Screw TH 8 x 30 1
22831 Screw TH 12 x 35
22855 Screw TH 14 x 40
K 18048 Nut M8 1
22832 Nut M12
22857 Nut M14
L 18045 Nut M4 2 2
M 18076 Washer L8 1
18078 Washer L12
N 18090 Split pin 2x20 1
18092 Split pin 2.5x30
O 22836 Shoudered clevis pin dia 8 1
22837 Shoudered clevis pin dia
12
P+V 22844 1+4 1+4
Q 17067 Halyard swivel 1 1
17070 "
R 19451 Crank shackle
S 26321 top end stop 1 1
T 25674 Screw Chc M5 x 12 1 1
U 25672 Screw N°10 (4.8x12.7) 1 1
V 25872 Screw TF N°7 (3.9x12.7) 4 4
W 27127 Screw TF M5 x 8 6+2 6+2
* Screw TF N°7 (3.9x12.7)
Bolt rope feeder + Screw*
