25
Référence Reference N° 608-S 608-S
25724 25725
A 25752 Base 1 1
B 25392 Alloy spar 5 5
C 25384 Coupling sleeve 6 6
D 26179 PVC liner 6 6
E 25675 Screw TCL M4 x 12
F 22827 Bearing 2 2
G 10001 Drum
10003 " 1 1
10008 "
H 26324 Reefing line adjuster
I 26325 Coupling plates 5 holes
21308 11 holes
21291 5 holes 1
21295 11 holes 1
22850 5 holes
J 18109 Screw TH 8 x 30
22831 Screw TH 12 x 35 1
22855 Screw TH 14 x 40
K 18048 Nut M8
22832 Nut M12 1
22857 Nut M14
L 18045 Nut M4
M 18076 Washer L8
18078 Washer L12 1
N 18090 Split pin 2x20
18092 Split pin 2.5x30 1
O 22836 Shoudered clevis pin dia 8
22837 Shoudered clevis pin dia 12 1
Q 17067 Halyard swivel
17070 " 1 1
R 19451 Crank shackle 1 1
S 26321 top end stop 1 1
T 25674 Screw Chc M5 x 12 1 1
U 25672 Screw N°10 (4.8x12.7) 1 1
V 25872 Screw TF N°7 (3.9x12.7) 4 4
W 27217 Screw TF M5 x 8 10+2 10+2
* Screw TF N°7 (3.9x12.7)
Bolt rope feeder + Screw*
P+V 22844 1+4 BOLT ROPE FEEDER1+4
