27
Référence Reference N° 810-S
25374
A 25752 Base 1
B 25392 Alloy spar 6
C 25384 Coupling sleeve 7
D 26179 PVC liner 7
E 25675 Screw TCL M4 x 12
F 22827 Bearing 2
G 10001 Drum
10003 "
10008 " 1
H 26324 Reefing line adjuster
I 26325 Coupling plates 5 holes
21308 11 holes
21291 5 holes
21295 11 holes
22850 5 holes 2
J 18109 Screw TH 8 x 30
22831 Screw TH 12 x 35
22855 Screw TH 14 x 40 1
K 18048 Nut M8
22832 Nut M12
22857 Nut M14 1
L 18045 Nut M4
M 18076 Washer L8
18078 Washer L12
N 18090 Split pin 2x20
18092 Split pin 2.5x30
O 22836 Shoudered clevis pin dia 8
22837 Shoudered clevis pin dia
12
Q 17067 Halyard swivel
17070 " 1
R 19451 Crank shackle 1
S 26321 top end stop 1
T 25674 Screw Chc M5 x 12 1
U 25672 Screw N°10 (4.8x12.7) 1
V 25872 Screw TF N°7 (3.9x12.7) 4
W 27127 Screw TF M5 x 8 12+2
* Screw TF N°7 (3.9x12.7)
Bolt rope feeder + Screw*
P+V 22844 1+4
