04 - Removable wheels
To install the wheels and remove them, it is necessary to access the four locks located in
the lower part of the suitcase.
Wheels locks
Installation
Follow steps 1 to 3 to remove the locks and install the wheels.
Slide and hold the safety lock back and place
the wheel bolt in the hole in the support
following the shape of the wheel.
Put pressure on the wheel until the bolt fully
enters the support orifice.
Bolt
Support orifice
11RUNNER User's manual
