Plinius SA-50 instruction manual. Page 13
MAINS / LINE POWER CONNECTION
MAINS / LINE POWER connection is via the supplied plug-in lead.
The standard IEC socket connects the mains power at the amplifier end while a local mains plug is
required at the wall end. In the event where a "local" plug needs to be fitted to the wall end of the lead,
ensure that the plug is wired correctly by a suitably qualified or experienced person.
The wiring code is;
Green to Earth,
Blue to Neutral,
Brown to Phase or Live.
Ensure the mains switch on the front of the amplifier is OFF before attempting any modification of the
mains connection.
Depress the left hand side of the MAINS switch. See page 4.
MAINS / LINE FUSE.
A Mains / Line fuse is fitted within the IEC Mains / Line socket on the rear of the amplifier. A small
draw at the bottom of this socket may be removed ( after the IEC plug is removed ) by levering it out with
a flat blade screw driver. The fuse fitted should be rated at no greater than 10 Amps Slow-Blow.
In the unusual event that this fuse should blow, you must first establish the cause of this failure, cure the
fault and then replace the fuse with one of the same type.
DO NOT FIT A FUSE WITH A HIGHER RATING without consulting your Plinius dealer first.
