Plinius SA-50 instruction manual. Page 22
SPECIFICATIONS
50 WATTS PER CHANNEL INTO 8 OHMS BOTH CHANNELS DRIVEN FROM 20Hz TO
20kHz AT 0.09% TOTAL HARMONIC DISTORTION FROM 0.25WATTS TO RATED
OUTPUT.
100 Watts RMS per channel 20Hz to 20kHz into 4 ohms.
BRIDGED OUTPUT:
200 Watts RMS 20Hz to 20kHz into 8 Ohms. (Mono).
DYNAMIC HEADROOM:
1dB or greater at 8 Ohms with music.
FREQUENCY RESPONSE:
20Hz to 20kHz ±0.1dB. 0dB at 0Hz and -1dB at 120kHz
DISTORTION:
Typically 0.01% THD and IMD at rated power. 0.1% THD and IM worst case prior to clipping.
SATURATION:
55 Watts per channel or greater into 8 ohms.
VOLTAGE SWING:
60 Volts peak to peak per channel.
CURRENT OUTPUT:
30 Amps short duration continuous per channel. Fuse protected.
RISE TIME:
Typically 2 microseconds.
PHASE RESPONSE:
+0º at 20Hz -2º at 20kHz.
HUM & NOISE:
100dB below rated output 20Hz to 20kHz, A weighted.
INPUT SENSITIVITY:
1 Volt RMS for rated output at 1kHz.
INPUT IMPEDANCE:
100,000 Ohms.
