1 - Introduction to the PowerSquare 160 - Description of the PowerSquare 160
Morgana PowerSquare™ 160 User Manual 7
The Side-Trimmer
Component - Function Table
1
2
3
5
6
7
8
9
4
FIGURE 4. Side-Trimmer Components
No. Component Function
1 The Top Cover The top cover opens to allow error recovery.
2 The Stacker The stacker collects the finished books.
3 The Trim Bin The trim bin collects the paper that is trimmed
from the top and bottom of the book.
4 Communications cable The communications cable connects the Side-
Trimmer to the PowerSquare 160.
5 Voltage label The voltage label displays the machine voltage.
6 Mains power input
connector
The mains power input connector is used to
connect the Side-Trimmer to mains electrical
power.
7 Mains power ON/OFF
switch
The mains power ON/OFF switch turns ON the
Side-Trimmer or turns OFF the Side-Trimmer.
