Loop Handle Installation
[Model BCH25, BCH35]
1. Place the loop handle and the bottom clamp on the shaft approximately
28cm(11 inches) from the end of the stop switch/throttle trigger assembly.
2. Install the four screws and nuts. Tighten the screws evenly.
3. Reposition the loop handle up or down the driveshaft to the
most comfortable position, and tighten the screw and nuts.
Loop Handle
Screw
(
4
)
Bottom Clamp
Nut
(
4
)
[BCH25, BCH35]
