7.11.2 Thermostat settings
This parameter enables or disables operation
of particular ecoSTER200 thermostats.
Enabling or disabling thermostat 2
or 3 is possible only in case when
there are additional external
temperature sensors connected to
the ecoSTER200 room panel.
When thermostat 2 or 3 is disabled,
its main screen is not displayed.
7.11.3 Hysteresis.
This parameter defines hysteresis of room
temperature. It decides of room temperature
at which the room thermostat will inform the
boiler regulator to heat. The boiler regulator
will start heating when the room temperature
drops under the current preset temperature
minus hysteresis. It will finish heating when
the current preset room temperature is
reached.
7.11.4 Temperature correction
This parameter enables to make corrections
of measured thermostat temperature within
a range of -3.0°C to +3.0°C.
Warning! The changes are not
visible immediately. Wait 5 minutes
to adjustment was taken into
account.
7.11.5 Language change
In order to change menu language, select:
MENU → Settings → Language
and select required language from the list.
7.11.6 Sound alarm
This parameter decided whether during the
alarm there will be a sound signal generated
in the ecoSTER200 panel.
7.11.7 Clock settings
In order to set time and date, select:
MENU → Settings → Clock
According to set date, the device will
automatically set an appropriate weekday.
The ecoSTER200 panel is equipped with a
system clock which is independent of the
boiler regulator clock, and therefore both
clocks have to be set on the same hour.
Programmed schedule works
according to the scoSTER200 panel
clock.
7.11.8 Brightness screen setting
The panel has the ability to set three
separate levels of screen brightness
separately for day, night and when editing
parameters. To adjust the brightness for the
selected level, go to the MENU → Settings
→ Brightness, and then set [%] intensity.
The panel based on the internal
system clock settings independently
activates the programmed level of
brightness in daylight hours and
night.
7.11.9 Information
In this window you can obtain information
concerning software version of the
ecoSTER200 panel and connected ecoMAX
boiler regulator.
8. Instructions for panel assembly
8.1 Technical data
Power source
+5V..12VCC
Current consumed by the device
I = 0.1 A
Protection level of the regulator
IP20
Ambient temperature
0...50 °C
Storage temperature
0...65 °C
Temperature measurement range
0...50 °C
Temperature regulation range
5...35 °C
Hysteresis
0.2…5 °C
Relative humidity
5– 85% without
condensation
Terminals
Elastic clamps
0.25– 2.5mm
2
Display
Graphic 128x64
External dimensions
164x90x40 mm
Complete weight
0.2 kg
Standards
PN-EN 60730-2-9
PN-EN 60730-1
Software class
A
