INSTALLATION
C-8
MacR6-
Z0
–
USER MA
NUAL
RF
-
1
–
T
YPE GAS METER ASSEMBLY
MacR6-
Z0
on RF-
1 gas meter type
:
•
replace
the
default
front
cover
for
the
addit
ional
with
emitter
and
cable
i
nserted
th
rough
–
delivered with t
he adapter
•
connect the wire
s to the termi
nals board in
MacR6-Z0
device:
pin
Signal
Wire
1
Pulse inp
ut
Digital Input
(DI1
+)
Yellow
2
GND
Brown
3
Tamper Swi
tch (DI2
+)
Green
Terminals boar
d in MacR6-
Z0 recorder
22
24
