Plum MacR6-Z0 User Manual

INSTALLATION
C-3
MacR6-Z0 – USER MANUAL
SIM CARD ASSEMBLY
To insert the SIM card take off the front cover. Remove six TORX T10 screws from back of the cover. Next
place the Micro SIM card into the holder as shown in the picture. There is no need to remove the battery to
insert the SIM card. SIM card must meet the requirements of ETSI TS 102221 v 9.0.0 or Embedded-SIM -
it is essential for proper device operation in whole temperatures range. In the next step put the device
together and tighten the screws with 0,65-0,75Nm momentum.
SIM card assembly in MacR6-Z0
SIM card assembly is allowed only out of the hazardous explosive zone.

Plum MacR6-Z0 Specifications

General

Brand	Plum
Model	MacR6-Z0
Category	Voice Recorder
Language	English
