SETTINGS
D-15
MacR6-Z0 – USER MANUAL
Function of the indicators (A):
- time indicator (muted - current billing month / flashing - previous billing month)
- counter indicator / MacR6-Z0 - V value / MacR6-V2 - V1 value / MacR6-PT - P value
- increments indicator
- peak hour indicator
- physical value indicator / MacR6-Z0: muted - volume / flashed - energy // MacR6-V2 - V2 value
Content presented on display, marked as A are pre-defined by the manufacturer.
Parameters display configuration can be changed by the user using PlumCONF.
Combinations of the markers on MacR6-Z0 display:
Turned on indicators
(A)
On display value
(L)
Billing period
Current date and time
current
Current value of volume counter
Volume increment from the last registration
period
Volume peak hour
Current value of energy counter
