Fusion process Operating Instructions MSA 2 CF
14
2.5 Enter operator code/job number
At the beginning you may add some work site information, like
the operator code and the job number for the next welding.
The reading of the operator code can be set as mandatory or left
optional.
When the leads are properly connected to the fitting, the control
unit checks the fitting resistance and displays it.
Before the acquisition of the fusion parameters, you can read
with the scanner the operator code (ISO 12176-3 compliant) and
the job number.
Alternatively, you can enter operator code and job number
manually, pressing the STOP button for 2” to enable the “edit”
mode, and then inserting the characters using () and () and
() () to change field. Once the data are entered, you can
confirm with the START button.
t = ----s
Vo= --.-V
R = 07.45Ω
------
------
12/06/19 15:50 70°F
The information will be shown above the barcode icon, in place
of the dash (‘-‘) symbols
t = ----s
Vo= --.-V
R = 07.45Ω
JSMITH
A116…
12/06/19 15:50 70°F
In case the operator code is mandatory the first row ‘----‘ will
blink and the MSA 2 CF will not move forward until the operator
