+GF+ SG 160 - Page 49

Operating instructions SG 160 9 Fusion data
45
S 8.3
SDR 17.6
PN 6
Ø
32 40 50 63 75 90 110 125 140 160
e: wall thickness
mm
– – 2,9 3,6 4.3 5.1 6.3 7.1 8.0 9.1
A: Fusion surface
mm²
– – 421 671 955 1360 2052 2629 3317 4314
F1&F5 : fusion force
daN
– – 4 7 10 14 21 26 33 43
Bead / Wulst / Bordino
mm
– – 0.5 0.5 0.5 0.5 0.5 1.0 1.0 1.0
F2: heating force
daN
– –
1 1 1 1 2 3 3 4
t2: heating time
sec
– – 87 108 129 145 164 176 189 204
t3: change over time
sec
– – 5 5 5 5 6 6 6 6
t4: Pressure buildup time
sec
– – 6 6 6 6 7 7 8 9
t5: Cooling time
min
– – 6 6 6 7 10 12 14 15
S 5
SDR 11
PN 10
Ø
32 40 50 63 75 90 110 125 140 160
e: wall thickness
mm
2.9
3,7 4,6 5.8 6.8 8.2 10.0 11.4 12.7 14.6
A: Fusion surface
mm²
265
415 656 1042 1457 2107 3141 4068 5079 6669
F1&F5 : fusion force
daN
3
4 7 10 15 21 31 41 51 67
Bead / Wulst / Bordino
mm
0.5
0.5 0.5 0.5 0.5 1.0 1.0 1.0 1.0 1.0
F2: heating force
daN
1
1 1 1 1 2 3 4 5 7
t2: heating time
sec
135
111 135 156 172 192 217 237 254 277
t3: change over time
se
c
5
5 5 6 6 6 7 7 7 8
t4: Pressure buildup time
sec
6
5 5 7 7 8 10 11 12 15
t5: Cooling time
min
6
6 6 9 12 14 17 19 21 24
S 3.2
SDR 7.4
PN 16
Ø
32 40 50 63 75 90 110 125 140 160
e: wall thickness
mm
4.4
5.5 6.9 8.6 10.3 12.3 15.1 17.1 19.2 21.9
A: Fusion surface
mm²
381
596 934 1470 2093 3002 4502 5796 7286 9501
F1&F5 : fusion force
daN
4
6 9 15 21 30 45 58 73 95
Bead / Wulst / Bordino
mm
0.5
0.5 0.5 1.0 1.0 1.0 1.0 1.0 1.5 1.5
F2: heating force
daN
1
1 1 1 2 3 5 6 7 10
t2: heating tim
e
sec
135
173 173 197 221 249 283 307 332 359
t3: change over time
sec
5
5 6 6 7 7 8 8 9 10
t4: Pressure buildup time
sec
6
6 7 8 10 11 14 15 17 19
t5: Cooling time
min
6
8 12 15 17 20 23 26 30 34
