9 Fusion data Operating instructions SG 160
44
Ø Outside pipe diameter
e Wall thickness
A Fusion surface
F1 Equalization force
F2 Heating force
F5 Fusion force
S20
SDR 41
PN 2.5
Ø
32 40 50 63 75 90 110 125 140 160
e: wall thickness
mm
– – – – 1,9 2,2 2.7 3.1 3.5 4.0
A: Fusion surface
mm²
– – – – 436 607 910 1187 1500 1960
F1&F5 : fusion force
daN
– – – – 4 6 9 12 15 20
Bead / Wulst / Bordino
mm
– – – – 0.5 0.5 0.5 0.5 0.5 0.5
F
2: heating force
daN
– – – –
1 1 1 1 2 2
t2: heating time
sec
– – – – 57 66 81 93 105 120
t3: change over time
sec
– – – – 5 5 5 5 5 5
t4: Pressure buildup time
sec
– – – – 6 6 6 6 6 6
t5: Cooling time
min
– – – – 6 6 6 6 6 6
S 16
SDR 33
PN 3.2
Ø
32 40 50 63 75 90 110 125 140 160
e: wall thickness
mm
– – – 2,0 2,3 2,8 3.4 3.9 4.3 4.9
A: Fusion surface
mm²
– – – 383 525 767 1138 1484 1833 2387
F1&F5 : fusion force
daN
– – – 4 5 8 11 15 18 24
Bead / Wulst / Bordino
mm
– – – 0.5 0.5 0.5 0.5 0.5 0.5 0.5
F2: heating force
daN
– – –
1 1 1 1 1 2 2
t2: heating time
sec
– – – 60 69 84 102 117 129 143
t3: change over time
sec
– – – 5 5 5 5 5 5 5
t4: Pressure buildup time
sec
– – – 6 6 6 6 6 6 6
t5: Cooling time
min
– – – 6 6 6 6 6 6 7
S 12.5
SDR 26
PN 4
Ø
32 40 50 63 75 90 110 125 140 160
e: wall thickness
mm
– – – 2,5 2,9 3.5 4.2 4.8 5.4 6.2
A: Fusion surface
mm²
– – – 475 656 951 1396 1812 2283 2995
F1&F5 : fusion force
daN
– – – 5 7 10 14 18 23 30
Bead / Wulst / Bordino
mm
– – – 0.5 0.5 0.5 0.5 0.5 0.5 0.5
F2: heating force
daN
– – –
1 1 1 1 2 2 3
t2: heating time
sec
– – – 75 87 105 126 140 149 162
t3: change over time
sec
– – – 5 5 5 5 5 5 6
t4: Pressure buildup time
sec
– – – 6 6 6 6 6 6 7
t5: Cooling time
min
– – – 6 6 6 6 7 8 10
