Appendix A: Specifications
4
Plustek MobileOffice D430
Image Sensor CIS x 2
Optical Resolution 600 dpi
Hardware Resolution 600 x 600 dpi
Scan Modes
Color: 48-bit Input; 24-bit Output
Grayscale: 16-bit Input; 8-bit Output
B/W: 1-bit
Scanning Speed
Simplex: 1.8 sec (Grayscale Mode, 200 dpi, A4)
Duplex: 2.4 sec (Grayscale Mode, 200 dpi, A4)
Scanning Area (W x L)
Max.: 216 x 1270 mm (8.5" x 50")
Min.: 12.7 x 12.7 mm (0.5" x 0.5")
Acceptable Paper Sizes
(W x L)
Max.: 240 x 1270 mm (9.45" x 50")
Min.: 30 x 35 mm (1.18" x 1.38")
Acceptable Paper Weight
(Thickness)
Paper: 50 g/㎡ to 125 g/㎡
Plastic card: Non-Embossed up to 0.76 mm &
Embossed up to 1.24 mm (ISO 7810)
Daily Duty Scan ( Sheets ) 1000
Action Button Scan, Function x 2 (Up & Down)
Power Supply AC Adapter: 24 Vdc/ 0.75 A
Interface USB 2.0
Net Weight 0.96 Kgs (2.13 Lbs)
Dimensions (W x D x H) 303 x 94 x 60 mm (11.93" x 3.7" x 2.36")
Protocol TWAIN compliant
4
Hardware specifications may change at any time without prior notice.
