9. Adjustment protocole
Function Factory set Projected Adjusted
value value value
Temperature Regulation function FRT ......................................
Set value, °C — ......................................
Min temp, °C — ......................................
Diff temp, °C 3,0 ......................................
Step 2 ......................................
Break point, °C 22,0 ......................................
Flow High speed supply air, l/s 200, 400, 700 * ......................................
Low speed supply air, l/s 100, 200, 400 * ......................................
High speed exhaust air, l/s 200, 400, 700 * ......................................
Low speed exhaust air, l/s 100, 200, 400 * ......................................
*) The three values is for ................................................
size 1, 2 respective 3.
Functions Summer night cooling 0 ......................................
Outdoor air temp. compensation 0 ......................................
Set value displcement 0 ......................................
Cooling unit on/off, Stepless 0-10V 0 ......................................
......................................
Duct calibration carried out — ......................................
Service period, months 12 ......................................
Ext high speed/low speed input
switch off delay, hours:min 0:00 ......................................
closure = high speed/low speed high speed ......................................
Time for filter test 22:59 ......................................
Anti freeze guard function 0 ......................................
(When having water coil.
Demands anti freeze guard sensor.)
Alarm limit filter guard
Supply air filter, units 10
**
......................................
Exhaust air filter, units 10 ** ......................................
**) Corr. to rec. final pressure
Times for high speed
No 1 ............ – .............. DAY ........
No 2 ............ – .............. DAY ........
No 3 ............ – .............. DAY ........
No 4 ............ – .............. DAY ........
No 5 ............ – .............. DAY ........
No 6 ............ – .............. DAY ........
No 7 ............ – .............. DAY ........
No 8 ............ – .............. DAY ........
No 9 ............ – .............. DAY ........
No 10 .......... – .............. DAY ........
No 11 .......... – .............. DAY ........
No 12 .......... – .............. DAY ........
Switching clock, actual time set Program version.............................
