7. ADJUSTMENTS
7.1 General
Push the buttons, according to sketch, until you reach
the group you want to read off or alter.
The functions of the buttons within the group are as
follows:
Turn forward between pictures in the
group.
Turn backwards between pictures in the
group.
RET Return to previous level.
PROG Alter to shown picture altering mode.
+ Step up the value for the flashing
numbers.
- Step down the value for the flashing
numbers.
SET Step forward so that new numbers
flashes. After the last numbers, alter back to
read off mode.
See also 9. Adjustment protocole!
➜
➜
::::
::::
::::
➜
➜
:::: ::::
➜
➜
::::
::::
HIGH SPEED 00.00–00.00
DAY 1
NO 1
➜
➜
RET PROG
::::
COOLING UNIT 0
DUCT CALIBR 0
SERV PERIOD 12 MONTHS
RET PROG
➜
➜
::::
➜
➜
::::
ANTI FR GUARD FUNC 0
RET PROG
➜
➜
::::
SUPP AIR FILTER
FILTER STATUS NOW 01
ALARM LIMIT 10
RET PROG
➜
➜
::::
RET PROG
➜
➜
::::
1 = SVENSKA
2 = ENGLISH
RET PROG
➜
➜
MAN STOP S-CL PROG
*GOLD* DAY 1 – 10:15
HIGH SPEED
AUTO OPER
ACTUAL TIME
DAY 1 – 10:15
RET PROG
*GOLD* DAY 1 – 10:15
PV 02:2 : OPER 0250D
SETTING
TEMP FLOW RET FUNC
ERS-REG STEP 2
OFF/ON-DIFF 3
°C
BREAKPOINT 22
°C
RET PROG RET PROG
HIGH SPEED:: LOW SPEED
700 l/s SA 400 l/s
700 l/s EA 400 l/s
SUMMER NIGHT COOL 0
OUTD A TEMP COMP 0
SET VALUE DISPL 0
RET PROG
RET PROG
EXT HS TIME DELAY 0:00
CLOSURE=HIGH SPEED
TIME FILTER TEST 22.59
EXH AIR FILTER
FILTER STATUS NOW 01
ALARM LIMIT 10
