PMA KS40-1 User Manual

4 Configuration level
4.1
Configuration with qUIC
At configuration level, the controller function is determined by changing configu
-
ration word Con1 . Con1 and the code adjusted for Con1 are displayed al
-
ternately on the lower display line.
Code signification:
Configuration level
KS40-1 burner 14 Configuration with qUIC
125
126
SP.X
SG
Err
Ada
r
Ì
È
Ì
Ù
3sec.
r
PArA
ConF
r
Ù
r
qUIC
Ù
r
Con1
r
r
Ù
r
123.8
1520
A
B
C
D
123.8
Con1
A 0 Reaction at sensor break as process value higher than set-point.
1 Reaction at sensor break as process value smaller than set-point
2 Only P30/W connection, always process value smaller than set-point *
B 0 Potentiometric transducer 50-30-50 [ / pressure sensor 0..10V, display range
0,0...100,0 (%)
1 Potentiometric transducer 50-30-50 [ / pressure sensor 0..10V, display range
0,00...1,00 (bar)
2 Potentiometric transducer 50-30-50 [ / pressure sensor 0..10V, display range
0,0...16,0 (bar)
3 Potentiometric transducer 50-30-50 [ / pressure sensor 0..10V, display range
0,0...40,0 (bar)
4 Resistance thermometer Pt 100 [ , range 0...200°C
5 Resistance thermometer Pt 100 [ , range 0...400°C
6 Thermocouple type L, range 0...900°C
7 Thermocouple type K, range 0...1350°C
C 0 Signaller with switching
1 3-point signaller
2 3-point stepping controller (DPS) switchable to signaller (SG)
3 3-point stepping controller (DPS) switchable to 3-point signaller (SG)
D 0 Not changeable
* Only possible with A = 2 and B = 0 … 3
