PMA KS40-1 User Manual

Maintenance manager / Error list
With one or several errors, the extended operating level
always starts with the error list. Signalling an actual en
-
try in the error list (alarm, error) is done by the Err LED
in the display. To reach the error list press Ù twice.
Error list:
Operation
Operating level 9 KS40-1 burner
125
126
SP.X
SG
Ada
Err
Err LED status Signification Proceed as follows
blinks Alarm due to existing error
-
Determine the error type in the error list via the error number
-
Remove the error
lit Error removed,
Alarm not acknowledged
-
Acknowledge the alarm in the error list pressing key È or Ì
-
The alarm entry was deleted.
off No error,all alarm entries deleted
Name
Description Cause Possible remedial action
E.1
Internal error,
cannot be
removed
-
E.g. defective EEPROM
-
Contact PMA service
- Return unit to our factory
E.2
Internal error,
can be reset
- e.g. EMC trouble - Keep measurementand power supply cables in
separate runs
- Ensure that interference suppression of contactors is
provided
FbF.1
/ 2
Sensor break
INP1 / 2
- Sensor defective
- Faulty cabling
- Replace INP1 / 2 sensor
- Check INP1 / 2 connection
Sht.1
/ 2
Short circuit
INP1 / 2
- Sensor defective
- Faulty cabling
- Replace INP1/ 2 sensor
- Check INP1 / 2 connection
POL.1
INP1 polarity
error
- Faulty cabling - Reverse INP1 polarity
LooP
Control loop
alarm (LOOP)
- Input signal defective or not
connected correctly
-
Output not connected correctly
- Check heating or cooling circuit
-
Check sensor and replace it, if necessary
-
Check controller and switching device
AdA.H
Self-tuning
heating alarm
(ADAH)
-
See Self-tuning heating error
status
-
see Self-tuning heating error status
LiM.1/
2 / 3
stored limit
alarm1/2/3
-
adjusted limit value1/2/3
exceeded
-
check process
Inf.1
time limit value
message
-
adjusted number of operating
hours reached
-
application-specific
