PART IDENTIFICATION
1
An asterisk (*) next to an item number represents a part that is different for specific models.
See the description in the part list table for details.
65
"A" PUMP ASSEMBLY; SIZE 120 (PU-05001-120)
ITEM
QTY
PART NUMBER
DESCRIPTION
1
1
PU-05013
"A" PACKING RETAINER FLANGE
2
1
OR-00020A
#136 VITON LUBE CYLINDER O-RING
3
4
PU-05026
TIE ROD; 3/8-24
4
1
PU-01013A
CYLINDER FLANGE GASKET
5
1
PU-05014
PUMP FLANGE
6
1
PU-03000
TRIPLE LIP SEAL, 120
7
1
PU-03005
SHAFT BEARING, 120, A
8
2
OR-00046A
O-RING #133; VITON 90D PUMP CYL
9
1
PU-05017
CROSSOVER TUBE
10
2
OR-00011A
O-RING; CROSSOVER TUBE #014
11
1
PU-05012
CYLINDER
12
1
-
PUMP BASE ASSEMBLY (SEE PAGE 69)
13
1
-
PISTON ASSEMBLY (SEE PAGE 68)
14
4
PU-05027
WASHER
15
4
PU-05028
NUT
16
1
HI-05038
1/4 NPT X 9/16-18 JIC 90 DEG E
17
1
HI-05016
3/4 MPT X 3/4 FPT SW
