PMC PH-55 - Motor Line Assembly

PART IDENTIFICATION
11
MOTOR LINE ASSEMBLY
(ML-55)
MOTOR LINE ASSEMBLY (ML-55)
ITEM
QTY
PART NUMBER
DESCRIPTION
1
1
200185
7.5 WEG MOTOR, PH(X)-55
2
1
200188
BELL HOUSING, 2-BOLT, PH(X)-55
3
1
200192
28CC PUMP, PH(X)-55
4
1
200187
1-1/4” NPT FLANGE
5
1
200189
MAGNALOY HUB, PH(X)-55
6
1
200191
COUPLING INSERT, 3/4” BORE
7
1
200190
MAGNALOY COUPLING, 7/8 X 1/5
8
1
200193
FITTING, 8 ORB X 6 JIC MALE ELBOW
9
1
200182
1.25X16 BLACK PUPE FOR HYDRAULIC, PH(X)-55
