TECHNICAL SPECIFICATIONS
ELECTRICAL
Main Voltage: ______________________________________ 3 x 208-230V, 50/60Hz
Electrical Consumption: ___________________________________ 107 A @ 3 x 230V
Material Heater Power: _____________________________________________ 21 kW
Hose Transformer Power: ____________________________________ 5 KVA (120 V)
Electrical Motor Power: ____________________________________________ 7.5 HP
Frequency: _______________________________________________________ 60 Hz
CAUTION! Inside the console is a Terminal Strip for
connecting the main power (wire not supplied) to the
PH Series Proportioner. This electrical connection
must be made only by a qualified electrician.
MECHANICAL
Maximum working pressure (PH-55): ________________________ 2,500 psi (172 bar)
Maximum working pressure (PHX-55): _______________________ 3,500 psi (241 bar)
Maximum production ratio 1:1 (PH-55): ____________________ 55 lbs/min (25 kg/min)
Maximum production ratio 1:1 (PHX-55): _____________________ 3.5 GPM (13 LPM)
Minimum production (PH-55): __________________________________ 2 lb/min (1 kg)
Maximum hose length: _______________________________________ 410 ft (123 m)
Approximate weight (Hydraulic Tank empty): _____________________ 655 lbs (297 kg)
Approximate weight (Hydraulic Tank full @ 20 gal (76 liters) ________ 795 lbs (360 kg)
Dimensions (English): ______________________________ 40in W x 26in D x 53.5in H
Dimensions (Metric) ___________________________ (101cm W x 66cm D x 136cm H)
