Internal Antenna
(PG. 12)
Backlit LCD
Test Button
(2 Stage Trigger)
(PG. 12)
Power On/Off and
MODE Button (PG. 5)
Zone Toggle
Buttons
(A, B, C, D) (PG. 11)
Status LED
(PG. 12)
Channel Up/Down Buttons
(PG. 11)
Hot Shoe with
Locking Ring
READ ME FIRST:
Transceiver
• All equipment should be turned OFF when making connections.
Otherwise unwanted triggering or erratic behavior may occur.
• If operation is erratic, check batteries in all equipment rst.
• You will need a PocketWizard Transceiver/Receiving PocketWizard radio
for each remote ash.
• Set all radios to the same channel.
